Siphoned Drain

SIPHONED DRAIN

Thanks to its simple but effective compliance, the drain prevents contact between the sewerage system and environment and is easily to clean and inspect. Its contained height allows easy installations and doesn’t need too low heights at the insertion points into the sewerage system.

If the number of drains is properly sized, you have a very high draining floor capacity without creating unwanted slope games, fast to assembly, strong under all loadings and pleasant.

Characteristics
Product
Article Type A (mm) B (mm) C (mm) Ø (mm) Weight (kg) Flow (l/sec)
Art. CLF 100 10×10 100 3 30 40 0.85 0.6
Art. CLF 150 15×15 150 4 75 50 2.4 0.9
Art. CLF 200 20×20 200 8 90 63 4.9 2.3
Art. CLF 250 25×25 250 8 90 80 7 2.3
Art. CLF 320 32×32 320 10 90 80/100 8.2 2.3/2.6
